Pozice | Název | Popis | Sklad. číslo | Sklad | Cena | |||
---|---|---|---|---|---|---|---|---|
1 | Screw | 49535 | 3 | 24 Kč | ||||
2 | COVER, IDR/CLUTCH 4S 250N ASSY | F30005 | Do 10 dnů | 2 983 Kč | ||||
2 | BODY CLUTCH CYLINDER 250Fi D26 | F30006 | Do 10 dnů | 2 491 Kč | ||||
3 | O-Ring | 12252 | 5 | 10 Kč | ||||
4 | SPRING | F16445 | Do 10 dnů | 37 Kč | ||||
5 | O-RING, CLUTCH PISTON 125/250 | 12259 | 15 | 40 Kč | ||||
6 | PISTON CLUTCH CYLINDER 250F 26 | F35522 | Do 10 dnů | 285 Kč | ||||
7 | PIN 5 X 24 | F19518 | Do 10 dnů | 13 Kč | ||||
8 | OIL SEAL 9X13X3 | F04367 | 2 | 148 Kč | ||||
9 | SPACER CYLINDER 250N | F35523 | Do 10 dnů | 788 Kč | ||||
10 | Collar | 26211 | 5 | 61 Kč | ||||
11 | PROTECTION, PLASTIC, FRONT SPROCKET | F30944 | 1 | 198 Kč | ||||
12 | PROTECTION, ALUMINIUM, FRONT SPROCKET | F70370 | 1 | 143 Kč | ||||
13 | SPACER | F26460 | 1 | 99 Kč | ||||
14 | O-RING, 108 GEAR F.S. | F12302 | 10 | 5 Kč | ||||
15 | ROD, CLUTCH 192mm 250N | F35544 | 1 | 292 Kč | ||||
16 | Spacer | 48250 | 2 | 40 Kč | ||||
17 | NEEDLE CAGE 27 x 32 x 23.8 | F19510 | 1 | 385 Kč | ||||
18 | BUSH, PRIMARY GEAR 250Fi | F26422 | Do 10 dnů | 563 Kč | ||||
19 | COPPIA PRIMARIA Z60/18 250N | F40954 | Do 10 dnů | 10 772 Kč | ||||
19 | PRIMARY GEAR 59/17T | F40957 | Do 10 dnů | 10 576 Kč | ||||
20 | RUBBER, CLUTCH BASKET | 21005 | 8 | 39 Kč | ||||
21 | CLUTCH BASKET 250Fi M. 10/-> | F25257 | Do 10 dnů | 1 884 Kč | ||||
22 | Plate | 35262 | Do 10 dnů | 135 Kč | ||||
23 | Stud | 49202 | 8 | 12 Kč | ||||
24 | SHAFT, WATER PUMP 250Fi | F28658 | 1 | 591 Kč | ||||
25 | GEAR WATER PUMP 250N | F40915 | Do 10 dnů | 840 Kč | ||||
26 | BEARING WATER PUMP 250/09 | F03365 | Do 10 dnů | 378 Kč | ||||
27 | Oil Seal | F04363 | 3 | 139 Kč | ||||
28 | CIRCLIP INT. 23 | F49913 | Do 10 dnů | 8 Kč | ||||
29 | OIL SEAL 14-22-4 TYPE A F.S. | F04352 | 4 | 130 Kč | ||||
30 | DISC OIL PUMP 250 F.S. | F32529 | Do 10 dnů | 87 Kč | ||||
31 | OIL PLUG M20X1,5 | F49925 | 1 | 390 Kč | ||||
32 | WASHER 20,4X26X1,5 ALUM | F49920 | 3 | 10 Kč | ||||
33 | COVER, PRIMARY DRIVE 250N 11-> | F30961 | Do 10 dnů | 3 837 Kč | ||||
34 | CLUTCH CENTER 250Fi | F25256 | 1 | 2 664 Kč | ||||
34 | Holder, clutch center | 50123 | Do 10 dnů | 1 513 Kč | ||||
35 | Washer, clutch center | 35050 | 1 | 31 Kč | ||||
36 | Nut, clutch center | 49060 | 2 | 28 Kč | ||||
37 | CLUTCH DISC STEEL 1,8 mm 250Fi-2ks | F35596 | Do 10 dnů | 179 Kč | ||||
38 | CLUTCH PLATE, STEEL 1,5 250Fi-5ks | F35541 | Do 10 dnů | 158 Kč | ||||
39 | CLUTCH PLATE, FIBER 250Fi 4S-8ks | F35588 | Do 10 dnů | 608 Kč | ||||
40 | PIECE, CLUTCH PUSH | 35051 | Do 10 dnů | 261 Kč | ||||
41 | Needle cage | 19022 | Do 10 dnů | 198 Kč | ||||
42 | Washer | 19023 | Do 10 dnů | 72 Kč | ||||
43 | CLIP PISTON PIN | Cena za 1ks. Celkem na tomto rozkresu použito 2ks.... | 09006 | 1 | 8 Kč | |||
44 | PRESSURE PLATE, CLUTCH 250Fi | F25258 | Do 10 dnů | 1 763 Kč | ||||
45 | Spring, cluch | F16453 | Do 10 dnů | 80 Kč | ||||
46 | Washer | 49604 | Do 10 dnů | 7 Kč | ||||
47 | BOLT TCEI 6X20 | Cena za 1ks. Celkem na tomto rozkresu použito 4ks.... | 49484 | 4 | 22 Kč | |||
48 | OIL SEAL 8 X 22 X 7 TC | 04017 | 5 | 108 Kč | ||||
50 | Impeller | F28679 | Do 10 dnů | 517 Kč | ||||
51 | GASKET, H2O COVER 250Fi | F05833 | 1 | 81 Kč | ||||
52 | COVER, WATER PUMP 250Fi M.2011 | F30966 | Do 10 dnů | 1 970 Kč | ||||
53 | BOLT TCEI 5X55 | 49578 | Do 10 dnů | 7 Kč | ||||
54 | BOLT TCEI 5X20 | Cena za 1ks. Celkem na tomto rozkresu použito 2ks.... | 49476 | 4 | 20 Kč | |||
55 | PRIMARY DRIVE GEAR 59T 250ASSY | F40936 | Do 10 dnů | 12 829 Kč | ||||
56 | SCREW AIR BLED HYDRAUL.CLUTCH | 35264 | 1 | 159 Kč | ||||
57 | O-RING COVER WATER PUMP 250 4S | F12327 | Do 10 dnů | 28 Kč | ||||
58 | CAP, COVER WATER PUMP 250 4S | F49841 | Do 10 dnů | 219 Kč |
